Flat gate valve
Product range:
| Caliber | 2″~84″、DN50~DN600 |
|---|---|
| Pressure pounds | CL150~CL2500、PN10~PN64 |
| Main material | carbon steel, alloy steel, stainless steel, etc |
| Form of connection | Flange ends, butt weld ends, etc |
| Form of operation | Manual, electric, etc |
Citation standards
| Design criteria | API 600、GB/T 12234 |
|---|---|
| Structural length standard | ASME B16.10、GB/T 12221 |
| Flange standard | ASME B16.5 and ASME B16.47, GB/T 9124 |
| Pressure test standard | API 598、GB/T 26480 |
Design features
✔ fully on
✔ Welded valve seat
✔ Stem blow-out prevention design
✔ Seal separately
✔ Full guide rail design
✔ Elastic wedge gate
✔ The valve can remove the handwheel in the fully open position
✔ Small flow resistance, opening and closing save effort
✔ The opening and closing time is long, and the water hammer phenomenon is not easy to occur
$999,999.00
可超售
Guaranteed Safe Checkout
Features & Compatibility
This series is a regular product of gate valves, with complete models, sufficient inventory, and a variety of main body and parts materials. It has significant advantages such as light switch, reliable sealing, long service life, and wide range of applications. Passed API 624 micro-leakage certification.
