Female Gate Valve Z15W

Applicable temperature and medium

Specifications:	Applicable temperature (°C)	Applicable media		Applicable pressure
DN15-65	-20℃～150℃	Water, ≤ 0.4 MPa indoor pipeline gas, ≤0.6 MPa air, non-corrosive liquid		1.6

Main parts materials

Part name	Material Name
Valve body, gate plate, valve stem, valve cover, nut	Brass (HPb59-1)
Mid-mouth gasket, filler	Polytetrafluoroethylene (PTFE)
Handwheel	HE200

Product features:

● Simple shape, good manufacturing process, wide range of application, easy to install.

● The structure is reasonable and compact, the volume is small, and the closing part (gate) adopts a wedge structure, which can automatically compensate for the deformation of the valve body caused by abnormal load or temperature during work, and the sealing is safe and reliable.

● The medium can flow in any direction from both sides of the gate valve, which can achieve the purpose of connecting or cutting off.

Appearance and structure drawing

Internal thread gate valves are mainly used to cut off the flow of media on the fluid in the pipeline. Because copper material itself has strong corrosion resistance, it is widely used in pharmaceutical pipelines and pure water pipelines.
