Brass Adjustable Pressure Reducing Valve Y22X-16T
Dimensions and connection dimensions
| DN | T | L | B | H | G |
| 15 | R1/2 | 148 | 64 | 97 | 142 |
| 20 | R3/4 | 168 | 73 | 113 | 162 |
| 25 | R1 | 194 | 81 | 122 | 176 |
| 32 | R1/4 | 197 | 87 | 135 | 196 |
| 40 | R1/2 | 208 | 97 | 149 | 220 |
| 50 | R2 | 227 | 101 | 166 | 244 |
| Nominal pressure | 1.0MPa |
| Working medium | Water |
| Operating temperature | 0°C≤t≤70°C |
| Outlet pressure adjustment range | When the inlet pressure is 1.6MPa, the outlet pressure is 0.10MPa-0.6MPa. When the inlet pressure is less than 0.3MPa, the outlet pressure is reduced accordingly. |
Usage: This series of valves is suitable for opening and closing pipelines where the working medium is water, non-corrosive liquid, air, saturated steam, etc.
$999,999.00
可超售
Guaranteed Safe Checkout
Features & Compatibility
Usage: This series of valves is suitable for opening and closing pipelines where the working medium is water, non-corrosive liquid, air, saturated steam, etc.
